Polycast® Solacryl® SUVT
Polycast® Solacryl® SUVT
General Description
Polycast® Stabilized Ultraviolet Transmitting Sheet. Provides increased resistance to degradation of UV exposure, while transmitting increased UV suitable for suntan beds.
Mechanical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Residual Shrinkage (Internal Strain) | ASTM D4802 | 2.2 | % |
| Specific Gravity | ASTM D792 | 1.19 | na |
| Tensile Strength Elongation, Rupture | ASTM D638 | 7 | % |
| Tensile Strength Modulus of Elasticity | ASTM D638 | 400,000 | psi |
| Tensile Strength Yield | ASTM D638 | 8,600 | psi |
| Water Absorption 24 hr Immersion | 24 Hour Immersion | 0.2 | % |
Optical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Luminous Transmittance (total) | ASTM D1003 | 92 | % |
| Luminous Transmittance Haze | ASTM D1003 | <1 | % |
| Refractive Index | ASTM D542 | 1.49 | n/a |
Thermal
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Coefficient of Linear Thermal Expansion | ASTM D696 | 0.000042 | in/in/°F |
| Deflection Temperature Under Load | ASTM D648 | 200* | °F |
| Flammability | ASTM D635 | 1.2* | in/min |
| Hot Forming Temp | n/a | 260** | °F |
| Max Recommended Continuous Service Temp | n/a | 155 | °F |
| SelfIgnition Temp | ASTM D1929 | 830* | °F |
| Specific Heat 77°F | DuPont900 (Therm. An. Cal.) | 0.35 | BTU/(lb)(°F) |
Product Information
| Item | Description |
|---|---|
| Product Line | Polycast® |
| Item Code | Polycast® Solacryl® SUVT |
| Material Description | Cell Cast Acrylic |
| Product Description | Stabilized Ultra Violet Transmitting Sheet |
| Characteristics | Increased resistance to degradation of UV exposure. |
Polymers
| Polymer Tag | Polymer Name |
|---|---|
| Acrylic | Methyl Methacrylate Monomers |
Related Documents
| Title | Open |
|---|---|
| Polycast® Solacryl® SUVT Technical Bulletin | Open |
| Polycast® Solacryl® SUVT Cell Cast Acrylic Sheet Product Bulletin | Open |
The above data are average values for Polycast® cell cast acrylic sheet and should not be used for any specific purpose. Spartech will furnish any additional information you may require.
Customers are responsible for determining whether products and information are appropriate for their use, including the evaluation of all applicable laws. Spartech LLC assumes no liability for the accuracy or completeness of information contained herein, and such information is subject to change without notice. All products supplied are subject to the standard terms and conditions of sale of Spartech LLC. NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, IS MADE BY THIS TECHNICAL DATA SHEET. ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED.
