Royalite® R89
Royalite® R89
General Description
Royalite® R89 thermoplastic sheet is a weatherable PVC that provides excellent impact, color and gloss retention under outdoor exposure conditions. Its weather resistance is superior to other materials in its class. The high impact and tensile strength, high stiffness, good formability and excellent weatherability allow for cost reductions by supporting thinner-walled parts.
Technical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Specific Gravity (color dependent) | ASTM D-792 | 1.47 | n/a |
| Izod Impact (Notched) 72°F | ASTM D-256 | 10 | ft-lbs/in |
| Gardner Impact 72°F | ASTM D-5420 | 320 | in-lb |
| Tensile Strength | ASTM D-638 | 6,200 | psi |
| Flexural Strength | ASTM D-790 | 9,500 | psi |
| Flexural Modulus | ASTM D-790 | 320,000 | psi |
| Rockwell Hardness (R Scale) | ASTM D-785 | 100 | n/a |
| Heat Deflection Temperature @264 psi, Annealed | ASTM D-648 | 157 | °F |
| Mold Shrinkage | Internal | 0.005 - 0.007 | in/in |
| Motor Vehicle Safety Standard | FMVSS 302 | Passes | n/a |
| Flammability | UL 94 V-0 | Listed@ 0.060" | n/a |
| Flammability | UL 94-5VA | Listed@ 0.060" | n/a |
Product Information
| Item | Description |
|---|---|
| Product Line | Royalite® |
| Item Code | Royalite® R89 |
| Material Description | Rigid PVC |
| Product Description | Weatherable, flame-retardant, rigid PVC |
| Characteristics | Listed: UL 94 V-0 @ 0.060" |
| Applications |
|
Polymers
| Polymer Tag | Polymer Name |
|---|---|
| RPVC | Rigid Polyvinyl Chloride |
Related Documents
| Title | Open |
|---|---|
| TDS—Royalite® R89 | Open |
| AIS—Royalite® R89 | Open |
*All values based on 0.125" unless otherwise stated
